PSC Registers
www.ti.com
148
SPRUH91DMarch 2013Revised September 2016
Submit Documentation Feedback
Copyright © 2013–2016, Texas Instruments Incorporated
Power and Sleep Controller (PSC)
8.6 PSC Registers
Table 8-6 lists the memory-mapped registers for the PSC0 and Table 8-7 lists the memory-mapped
registers for the PSC1.
Table 8-6. Power and Sleep Controller 0 (PSC0) Registers
Address Acronym Register Description Section
01C1 0000h REVID Revision Identification Register Section 8.6.1
01C1 0018h INTEVAL Interrupt Evaluation Register Section 8.6.2
01C1 0040h MERRPR0 Module Error Pending Register 0 (module 0-15) Section 8.6.3
01C1 0050h MERRCR0 Module Error Clear Register 0 (module 0-15) Section 8.6.5
01C1 0060h PERRPR Power Error Pending Register Section 8.6.7
01C1 0068h PERRCR Power Error Clear Register Section 8.6.8
01C1 0120h PTCMD Power Domain Transition Command Register Section 8.6.9
01C1 0128h PTSTAT Power Domain Transition Status Register Section 8.6.10
01C1 0200h PDSTAT0 Power Domain 0 Status Register Section 8.6.11
01C1 0204h PDSTAT1 Power Domain 1 Status Register Section 8.6.12
01C1 0300h PDCTL0 Power Domain 0 Control Register Section 8.6.13
01C1 0304h PDCTL1 Power Domain 1 Control Register Section 8.6.14
01C1 0400h PDCFG0 Power Domain 0 Configuration Register Section 8.6.15
01C1 0404h PDCFG1 Power Domain 1 Configuration Register Section 8.6.16
01C1 0800h-
01C1 083Ch
MDSTAT0-
MDSTAT15
Module Status n Register (modules 0-15) Section 8.6.17
01C1 0A00h-
01C1 0A3Ch
MDCTL0-
MDCTL15
Module Control n Register (modules 0-15) Section 8.6.18
Table 8-7. Power and Sleep Controller 1 (PSC1) Registers
Address Acronym Register Description Section
01E2 7000h REVID Revision Identification Register Section 8.6.1
01E2 7018h INTEVAL Interrupt Evaluation Register Section 8.6.2
01E2 7040h MERRPR0 Module Error Pending Register 0 (module 0-31) Section 8.6.4
01E2 7050h MERRCR0 Module Error Clear Register 0 (module 0-31) Section 8.6.6
01E2 7060h PERRPR Power Error Pending Register Section 8.6.7
01E2 7068h PERRCR Power Error Clear Register Section 8.6.8
01E2 7120h PTCMD Power Domain Transition Command Register Section 8.6.9
01E2 7128h PTSTAT Power Domain Transition Status Register Section 8.6.10
01E2 7200h PDSTAT0 Power Domain 0 Status Register Section 8.6.11
01E2 7204h PDSTAT1 Power Domain 1 Status Register Section 8.6.12
01E2 7300h PDCTL0 Power Domain 0 Control Register Section 8.6.13
01E2 7304h PDCTL1 Power Domain 1 Control Register Section 8.6.14
01E2 7400h PDCFG0 Power Domain 0 Configuration Register Section 8.6.15
01E2 7404h PDCFG1 Power Domain 1 Configuration Register Section 8.6.16
01E2 7800h-
01E2 787Ch
MDSTAT0-
MDSTAT31
Module Status n Register (modules 0-31) Section 8.6.17
01E2 7A00h-
01E2 7A7Ch
MDCTL0-
MDCTL31
Module Control n Register (modules 0-31) Section 8.6.19
