Texas Instruments TMS320C6745 DSP - Timing Waveform of an Asynchronous Read Cycle in Select Strobe Mode

EMA_CLK
EMA_CS[n
]
EMA_WE_DQM
EMA_A/EMA_BA
EMA_D
EMA_OE
EMA_WE
Setup
Strobe
Hold
2
3
2
Byte enables
Address
Data
Architecture www.ti.com
720
SPRUH91D–March 2013–Revised September 2016
Submit Documentation Feedback
Copyright © 2013–2016, Texas Instruments Incorporated
External Memory Interface A (EMIFA)
Figure 18-12. Timing Waveform of an Asynchronous Read Cycle in Select Strobe Mode
