External Memory Interface A (EMIFA)
18.4.20 NAND Flash 4-Bit ECC Error Address Register 1 (NANDERRADD1)
The NAND Flash 4-bit ECC error register 1 (NANDERRADD1) is shown in Figure 18-50 and described in
Table 18-68.
Figure 18-50. NAND Flash 4-Bit ECC Error Address Register 1 (NANDERRADD1)
31 26 25 16
Reserved 4BITECCERRADD2
R-0 R/W-0
15 10 9 0
Reserved 4BITECCERRADD1
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 18-68. NAND Flash 4-Bit ECC Error Address Register 1 (NANDERRADD1) Field Descriptions
Bit Field Value Description
31-26 Reserved 0 Reserved
25-16 4BITECCERRADD2 0-3FFh Calculated 4-bit ECC Error Address 2.
15-10 Reserved 0 Reserved
9-0 4BITECCERRADD1 0-3FFh Calculated 4-bit ECC Error Address 1.
18.4.21 NAND Flash 4-Bit ECC Error Address Register 2 (NANDERRADD2)
The NAND Flash 4-bit ECC error register 2 (NANDERRADD2) is shown in Figure 18-51and described in
Table 18-69.
Figure 18-51. NAND Flash 4-Bit ECC Error Address Register 2 (NANDERRADD2)
31 26 25 16
Reserved 4BITECCERRADD4
R-0 R/W-0
15 10 9 0
Reserved 4BITECCERRADD3
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 18-69. NAND Flash 4-Bit ECC Error Address Register 2 (NANDERRADD2) Field Descriptions
Bit Field Value Description
31-26 Reserved 0 Reserved
25-16 4BITECCERRADD4 0-3FFh Calculated 4-bit ECC Error Address 4.
15-10 Reserved 0 Reserved
9-0 4BITECCERRADD3 0-3FFh Calculated 4-bit ECC Error Address 3.
