System Configuration (SYSCFG) Module
10.5.10.18 Pin Multiplexing Control 17 Register (PINMUX17)
Figure 10-35. Pin Multiplexing Control 17 Register (PINMUX17)
31 28 27 24 23 20 19 16
PINMUX17_31_28 PINMUX17_27_24 PINMUX17_23_20 PINMUX17_19_16
R/W-0 R/W-0 R/W-0 R/W-0
15 12 11 8 7 4 3 0
PINMUX17_15_12 PINMUX17_11_8 PINMUX17_7_4 PINMUX17_3_0
R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
(1)
The ZKB ball package is only available on the C6747 DSP; this package is not supported on the C6745 DSP.
(2)
The PTP pin package is only available on the C6745 DSP; this package is not supported on the C6747 DSP.
Table 10-39. Pin Multiplexing Control 17 Register (PINMUX17) Field Descriptions
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
31-28 PINMUX17_31_28 L16 — EMA_CAS/EMA_CS[4]/GP2[1] Control
0 Pin is 3-stated.
1h Selects Function EMA_CAS
2h Selects Function EMA_CS[4]
3h-7h Reserved
8h Selects Function GP2[1]
9h-Fh Reserved
27-24 PINMUX17_27_24 T12 — EMA_SDCKE/GP2[0] Control
0 Pin is 3-stated.
1h Selects Function EMA_SDCKE
2h-7h Reserved
8h Selects Function GP2[0]
9h-Fh Reserved
23-20 PINMUX17_23_20 R12 — EMA_CLK/OBSCLK/AHCLKR2/GP1[15] Control
0 Pin is 3-stated.
1h Selects Function EMA_CLK
2h Selects Function OBSCLK.
3h Reserved
4h Selects Function AHCLKR2
5h-7h Reserved
8h Selects Function GP1[15]
9h-Fh Reserved
19-16 PINMUX17_19_16 R8 25 EMA_BA[0]/LCD_D[4]/GP1[14] Control
0 Pin is 3-stated.
1h Selects Function EMA_BA[0]
2h Selects Function LCD_D[4]
3h-7h Reserved
8h Selects Function GP1[14]
9h-Fh Reserved
