Inter-Integrated Circuit (I2C) Module
22.3.5 I2C Data Count Register (ICCNT)
The I2C data count register (ICCNT) is used to indicate how many data words to transfer when the I2C is
configured as a master-transmitter-receiver (MST = 1 and TRX = 1/0 in ICMDR) and the repeat mode is
off (RM = 0 in ICMDR). In the repeat mode (RM = 1), ICCNT is not used.
The value written to ICCNT is copied to an internal data counter. The internal data counter is decremented
by 1 for each data word transferred (ICCNT remains unchanged). If a STOP condition is requested
(STP = 1 in ICMDR), the I2C terminates the transfer with a STOP condition when the countdown is
complete (that is, when the last data word has been transferred).
ICCNT is shown in Figure 22-18 and described in Table 22-10.
Figure 22-18. I2C Data Count Register (ICCNT)
31 16
Reserved
R-0
15 0
ICDC
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 22-10. I2C Data Count Register (ICCNT) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 These reserved bit locations are always read as zeros. A value written to this field has no effect.
15-0 ICDC 0-FFFFh Data count value. When RM = 0 in ICMDR, ICDC indicates the number of data words to transfer in
the nonrepeat mode. When RM = 1 in ICMDR, the value in ICCNT is a don't care. If STP = 1 in
ICMDR, a STOP condition is generated when the internal data counter counts down to 0.
0 The start value loaded to the internal data counter is 65536.
1h-FFFFh The start value loaded to internal data counter is 1-65535.
