Enhanced High-Resolution Pulse-Width Modulator (eHRPWM)
14.4.8.1 Time-Base Phase High-Resolution Register (TBPHSHR)
The time-base phase high-resolution register (TBPHSHR) is shown in Figure 14-92 and described in
Table 14-85.
Figure 14-92. Time-Base Phase High-Resolution Register (TBPHSHR)
15 8 7 0
TBPHSH Reserved
R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-85. Time-Base Phase High-Resolution Register (TBPHSHR) Field Descriptions
Bit Field Value Description
15-8 TBPHSH 0-FFh Time-base phase high-resolution bits
7-0 Reserved 0 Reserved
14.4.8.2 Counter-Compare A High-Resolution Register (CMPAHR)
The counter-compare A high-resolution register (CMPAHR) is shown in Figure 14-93 and described in
Table 14-86.
Figure 14-93. Counter-Compare A High-Resolution Register (CMPAHR)
15 8 7 0
CMPAHR Reserved
R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-86. Counter-Compare A High-Resolution Register (CMPAHR) Field Descriptions
Bit Field Value Description
15-8 CMPAHR 1-FFh Compare A High-Resolution register bits for MEP step control. A minimum value of 1h is needed to
enable HRPWM capabilities. Valid MEP range of operation 1-255h.
7-0 Reserved 0 Reserved
