16.4.2.5.5 Event Enable Register (EER)
The EDMA3CC provides the option of selectively enabling/disabling each event in the event register (ER)
by using the event enable register (EER). If an event bit in EER is set to 1 (using the event enable set
register, EESR), it will enable that corresponding event. Alternatively, if an event bit in EER is cleared
(using the event enable clear register, EECR), it will disable the corresponding event.
The event register latches all events that are captured by EDMA3CC, even if the events are disabled
(although EDMA3CC does not process it). Enabling an event with a pending event already set in the event
register enables the EDMA3CC to process the already set event like any other new event. The EER
settings do not have any effect on chained events (CER.En = 1) and manually set events (ESR.En = 1).
The EER is shown in Figure 16-65 and described in Table 16-44.
Figure 16-65. Event Enable Register (EER)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
E31 E30 E29 E28 E27 E26 E25 E24 E23 E22 E21 E20 E19 E18 E17 E16
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 16-44. Event Enable Register (EER) Field Descriptions
Bit Field Value Description
31-0 En Event enable for events 0-31.
0 Event is not enabled. An external event latched in the event register (ER) is not evaluated by the
EDMA3CC.
1 Event is enabled. An external event latched in the event register (ER) is evaluated by the EDMA3CC.
