Phase-Locked Loop Controller (PLLC)
7.4.18 PLL Controller Clock Align Control Register (ALNCTL)
The PLL controller clock align control register (ALNCTL) is shown in Figure 7-19 and described in Table 7-
20. Indicates which SYSCLKs need to be aligned for proper device operation.
Figure 7-19. PLL Controller Clock Align Control Register (ALNCTL)
31 16
Reserved
R-0
15 7 6 5 4 3 2 1 0
Reserved ALN7 ALN6 ALN5 ALN4 ALN3 ALN2 ALN1
R-0 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-20. PLL Controller Clock Align Control Register (ALNCTL) Field Descriptions
Bit Field Value Description
31-7 Reserved 0 Reserved
6 ALN7 SYSCLK7 needs to be aligned to others selected in this register.
0 No
1 Yes
5 ALN6 SYSCLK6 needs to be aligned to others selected in this register.
0 No
1 Yes
4 ALN5 SYSCLK5 needs to be aligned to others selected in this register.
0 No
1 Yes
3 ALN4 SYSCLK4 needs to be aligned to others selected in this register.
0 No
1 Yes
2 ALN3 SYSCLK3 needs to be aligned to others selected in this register.
0 No
1 Yes
1 ALN2 SYSCLK2 needs to be aligned to others selected in this register.
0 No
1 Yes
0 ALN1 SYSCLK1 needs to be aligned to others selected in this register.
0 No
1 Yes
