Inter-Integrated Circuit (I2C) Module
22.3.13 I2C Revision Identification Register (REVID1)
The I2C revision identification register (REVID1) contains identification data for the peripheral. REVID1 is
shown in Figure 22-27 and described in Table 22-20.
Figure 22-27. I2C Revision Identification Register 1 (REVID1)
31 0
REVID1
R-4415h
LEGEND: R = Read only; -n = value after reset
Table 22-20. I2C Revision Identification Register 1 (REVID1) Field Descriptions
Bit Field Value Description
31-0 REVID1 4415h Peripheral Identification Number
22.3.14 I2C Revision Identification Register (REVID2)
The I2C revision identification register (REVID2) contains identification data for the peripheral. REVID2 is
shown in Figure 22-28 and described in Table 22-21.
Figure 22-28. I2C Revision Identification Register 2 (REVID2)
31 0
REVID2
R-6h
LEGEND: R = Read only; -n = value after reset
Table 22-21. I2C Revision Identification Register 2 (REVID2) Field Descriptions
Bit Field Value Description
31-0 REVID2 6h Peripheral Identification Number
