10.5.10.6 Pin Multiplexing Control 5 Register (PINMUX5)
Figure 10-23. Pin Multiplexing Control 5 Register (PINMUX5)
31 28 27 24 23 20 19 16
PINMUX5_31_28 PINMUX5_27_24 PINMUX5_23_20 PINMUX5_19_16
R/W-0 R/W-0 R/W-0 R/W-0
15 12 11 8 7 4 3 0
PINMUX5_15_12 PINMUX5_11_8 PINMUX5_7_4 PINMUX5_3_0
R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
(1)
The ZKB ball package is only available on the C6747 DSP; this package is not supported on the C6745 DSP.
(2)
The PTP pin package is only available on the C6745 DSP; this package is not supported on the C6747 DSP.
Table 10-27. Pin Multiplexing Control 5 Register (PINMUX5) Field Descriptions
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
31-28 PINMUX5_31_28 J15 63 EMB_D[6]/GP6[6] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[6]
2h-7h Reserved
8h Selects Function GP6[6]
9h-Fh Reserved
27-24 PINMUX5_27_24 J13 64 EMB_D[5]/GP6[5] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[5]
2h-7h Reserved
8h Selects Function GP6[5]
9h-Fh Reserved
23-20 PINMUX5_23_20 H16 66 EMB_D[4]/GP6[4] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[4]
2h-7h Reserved
8h Selects Function GP6[4]
9h-Fh Reserved
19-16 PINMUX5_19_16 H13 68 EMB_D[3]/GP6[3] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[3]
2h-7h Reserved
8h Selects Function GP6[3]
9h-Fh Reserved
15-12 PINMUX5_15_12 G16 70 EMB_D[2]/GP6[2] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[2]
2h-7h Reserved
8h Selects Function GP6[2]
9h-Fh Reserved
