General-Purpose Input/Output (GPIO)
20.3.7 GPIO Input Data Registers (IN_DATAn)
The current state of the GPIO signals is read using the GPIO input data register (IN_DATAn).
• For GPIO signals configured as inputs, reading IN_DATAn returns the state of the input signal
synchronized to the GPIO peripheral clock.
• For GPIO signals configured as outputs, reading IN_DATAn returns the output value being driven by
the device.
The GPIO input data register (IN_DATA01) is shown in Figure 20-24, IN_DATA23 is shown in Figure 20-
25, IN_DATA45 is shown in Figure 20-26, IN_DATA67 is shown in Figure 20-27, IN_DATA8 is shown in
Figure 20-28, and described in Table 20-9. See Table 20-1 to determine the IN_DATAn bit associated with
each GPIO bank and pin number.
Figure 20-24. GPIO Banks 0 and 1 Input Data Register (IN_DATA01)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GP1P15 GP1P14 GP1P13 GP1P12 GP1P11 GP1P10 GP1P9 GP1P8 GP1P7 GP1P6 GP1P5 GP1P4 GP1P3 GP1P2 GP1P1 GP1P0
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP0P15 GP0P14 GP0P13 GP0P12 GP0P11 GP0P10 GP0P9 GP0P8 GP0P7 GP0P6 GP0P5 GP0P4 GP0P3 GP0P2 GP0P1 GP0P0
R-0
LEGEND: R = Read only; -n = value after reset
Figure 20-25. GPIO Banks 2 and 3 Input Data Register (IN_DATA23)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GP3P15 GP3P14 GP3P13 GP3P12 GP3P11 GP3P10 GP3P9 GP3P8 GP3P7 GP3P6 GP3P5 GP3P4 GP3P3 GP3P2 GP3P1 GP3P0
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP2P15 GP2P14 GP2P13 GP2P12 GP2P11 GP2P10 GP2P9 GP2P8 GP2P7 GP2P6 GP2P5 GP2P4 GP2P3 GP2P2 GP2P1 GP2P0
R-0
LEGEND: R = Read only; -n = value after reset
Figure 20-26. GPIO Banks 4 and 5 Input Data Register (IN_DATA45)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GP5P15 GP5P14 GP5P13 GP5P12 GP5P11 GP5P10 GP5P9 GP5P8 GP5P7 GP5P6 GP5P5 GP5P4 GP5P3 GP5P2 GP5P1 GP5P0
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP4P15 GP4P14 GP4P13 GP4P12 GP4P11 GP4P10 GP4P9 GP4P8 GP4P7 GP4P6 GP4P5 GP4P4 GP4P3 GP4P2 GP4P1 GP4P0
R-0
LEGEND: R = Read only; -n = value after reset
Figure 20-27. GPIO Banks 6 and 7 Input Data Register (IN_DATA67)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GP7P15 GP7P14 GP7P13 GP7P12 GP7P11 GP7P10 GP7P9 GP7P8 GP7P7 GP7P6 GP7P5 GP7P4 GP7P3 GP7P2 GP7P1 GP7P0
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP6P15 GP6P14 GP6P13 GP6P12 GP6P11 GP6P10 GP6P9 GP6P8 GP6P7 GP6P6 GP6P5 GP6P4 GP6P3 GP6P2 GP6P1 GP6P0
R-0
LEGEND: R = Read only; -n = value after reset
