External Memory Interface B (EMIFB)
19.4 Registers
The external memory interface (EMIFB) is controlled by programming its internal memory-mapped
registers (MMRs). Table 19-23 lists the memory-mapped registers of the EMIFB memory controller.
NOTE: All EMIFB MMRs support only word, that is, 32-bit, accesses. Performing a byte (8-bit) or
halfword (16-bit) write to these registers results in undefined behavior.
The EMIFB base controller registers must always be accessed using 32-bit accesses (unless otherwise
specified in this document). For the base address of the memory-mapped registers of EMIFB, see your
device-specific data manual.
Table 19-23. EMIFB Base Controller Registers
Offset Acronym Register Section
0h REVID Revision ID Register Revision ID
Register
(REVID)
8h SDCFG SDRAM Configuration Register Section 19.4.1
Ch SDRFC SDRAM Refresh Control Register Section 19.4.2
10h SDTIM1 SDRAM Timing 1 Register Section 19.4.3
14h SDTIM2 SDRAM Timing 2 Register Section 19.4.4
1Ch SDCFG2 SDRAM Configuration 2 Register SDRAM
Configuration 2
Register
(SDCFG2)
20h BPRIO Peripheral Bus Burst Priority Register Section 19.4.5
40h PC1 Performance Counter 1 Register Section 19.4.6
44h PC2 Performance Counter 2 Register Section 19.4.7
48h PCC Performance Counter Configuration Register Section 19.4.8
4Ch PCMRS Performance Counter Master Region Select Register Section 19.4.9
50h PCT Performance Counter Time Register Performance
Counter Time
Register (PCT)
C0h IRR Interrupt Raw Register Section 19.4.10
C4h IMR Interrupt Mask Register Section 19.4.11
C8h IMSR Interrupt Mask Set Register Section 19.4.12
CCh IMCR Interrupt Mask Clear Register Section 19.4.13
Revision ID Register (REVID)
This is read-only ID register of EMIFB. The REVID is shown in Figure 19-13 and described in Table 19-24.
Figure 19-13. Revision ID Register (REVID)
31 0
REV
R-4033 131Fh
LEGEND: R = Read only; -n = value after reset
Table 19-24. Revision ID Register (REVID) Field Descriptions
Bit Field Value Description
31-0 REV 4033 131Fh Revision ID value of EMIFB.
