Enhanced High-Resolution Pulse-Width Modulator (eHRPWM)
14.4.5 PWM-Chopper Submodule Register
The PWM-chopper control register (PCCTL) is shown in Figure 14-80 and described in Table 14-70.
Figure 14-80. PWM-Chopper Control Register (PCCTL)
15 11 10 8 7 5 4 1 0
Reserved CHPDUTY CHPFREQ OSHTWTH CHPEN
R-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-70. PWM-Chopper Control Register (PCCTL) Bit Descriptions
Bits Name Value Description
15-11 Reserved 0 Reserved
10-8 CHPDUTY 0-7h Chopping Clock Duty Cycle
0 Duty = 1/8 (12.5%)
1h Duty = 2/8 (25.0%)
2h Duty = 3/8 (37.5%)
3h Duty = 4/8 (50.0%)
4h Duty = 5/8 (62.5%)
5h Duty = 6/8 (75.0%)
6h Duty = 7/8 (87.5%)
7h Reserved
7-5 CHPFREQ 0-7h Chopping Clock Frequency
0 Divide by 1 (no prescale)
1h Divide by 2
2h Divide by 3
3h-7h Divide by 4 to divide by 8
4-1 OSHTWTH 0-Fh One-Shot Pulse Width
0 1 × SYSCLKOUT/8 wide
1h 2 × SYSCLKOUT/8 wide
2h 3 × SYSCLKOUT/8 wide
3h-Fh 4 × SYSCLKOUT/8 wide to 16 × SYSCLKOUT/8 wide
0 CHPEN PWM-chopping Enable
0 Disable (bypass) PWM chopping function
1 Enable chopping function
