EMAC/MDIO Module
17.3.3.1 Transmit Revision ID Register (TXREVID)
The transmit revision ID register (TXREVID) is shown in Figure 17-39 and described in Table 17-38.
Figure 17-39. Transmit Revision ID Register (TXREVID)
31 0
TXREV
R-4EC0 020Dh
LEGEND: R = Read only; -n = value after reset
Table 17-38. Transmit Revision ID Register (TXREVID) Field Descriptions
Bit Field Value Description
31-0 TXREV Transmit module revision
4EC0 020Dh Current transmit revision value
17.3.3.2 Transmit Control Register (TXCONTROL)
The transmit control register (TXCONTROL) is shown in Figure 17-40 and described in Table 17-39.
Figure 17-40. Transmit Control Register (TXCONTROL)
31 16
Reserved
R-0
15 1 0
Reserved TXEN
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 17-39. Transmit Control Register (TXCONTROL) Field Descriptions
Bit Field Value Description
31-1 Reserved 0 Reserved
0 TXEN Transmit enable
0 Transmit is disabled.
1 Transmit is enabled.
