EMAC/MDIO Module
Table 17-37. Ethernet Media Access Controller (EMAC) Registers (continued)
Offset Acronym Register Description Section
678h RX6CP Receive Channel 6 Completion Pointer Register Section 17.3.3.49
67Ch RX7CP Receive Channel 7 Completion Pointer Register Section 17.3.3.49
Network Statistics Registers
200h RXGOODFRAMES Good Receive Frames Register Section 17.3.3.50.1
204h RXBCASTFRAMES Broadcast Receive Frames Register Section 17.3.3.50.2
208h RXMCASTFRAMES Multicast Receive Frames Register Section 17.3.3.50.3
20Ch RXPAUSEFRAMES Pause Receive Frames Register Section 17.3.3.50.4
210h RXCRCERRORS Receive CRC Errors Register Section 17.3.3.50.5
214h RXALIGNCODEERRORS Receive Alignment/Code Errors Register Section 17.3.3.50.6
218h RXOVERSIZED Receive Oversized Frames Register Section 17.3.3.50.7
21Ch RXJABBER Receive Jabber Frames Register Section 17.3.3.50.8
220h RXUNDERSIZED Receive Undersized Frames Register Section 17.3.3.50.9
224h RXFRAGMENTS Receive Frame Fragments Register Section 17.3.3.50.10
228h RXFILTERED Filtered Receive Frames Register Section 17.3.3.50.11
22Ch RXQOSFILTERED Receive QOS Filtered Frames Register Section 17.3.3.50.12
230h RXOCTETS Receive Octet Frames Register Section 17.3.3.50.13
234h TXGOODFRAMES Good Transmit Frames Register Section 17.3.3.50.14
238h TXBCASTFRAMES Broadcast Transmit Frames Register Section 17.3.3.50.15
23Ch TXMCASTFRAMES Multicast Transmit Frames Register Section 17.3.3.50.16
240h TXPAUSEFRAMES Pause Transmit Frames Register Section 17.3.3.50.17
244h TXDEFERRED Deferred Transmit Frames Register Section 17.3.3.50.18
248h TXCOLLISION Transmit Collision Frames Register Section 17.3.3.50.19
24Ch TXSINGLECOLL Transmit Single Collision Frames Register Section 17.3.3.50.20
250h TXMULTICOLL Transmit Multiple Collision Frames Register Section 17.3.3.50.21
254h TXEXCESSIVECOLL Transmit Excessive Collision Frames Register Section 17.3.3.50.22
258h TXLATECOLL Transmit Late Collision Frames Register Section 17.3.3.50.23
25Ch TXUNDERRUN Transmit Underrun Error Register Section 17.3.3.50.24
260h TXCARRIERSENSE Transmit Carrier Sense Errors Register Section 17.3.3.50.25
264h TXOCTETS Transmit Octet Frames Register Section 17.3.3.50.26
268h FRAME64 Transmit and Receive 64 Octet Frames Register Section 17.3.3.50.27
26Ch FRAME65T127 Transmit and Receive 65 to 127 Octet Frames Register Section 17.3.3.50.28
270h FRAME128T255 Transmit and Receive 128 to 255 Octet Frames Register Section 17.3.3.50.29
274h FRAME256T511 Transmit and Receive 256 to 511 Octet Frames Register Section 17.3.3.50.30
278h FRAME512T1023 Transmit and Receive 512 to 1023 Octet Frames Register Section 17.3.3.50.31
27Ch FRAME1024TUP Transmit and Receive 1024 to RXMAXLEN Octet Frames
Register
Section 17.3.3.50.32
280h NETOCTETS Network Octet Frames Register Section 17.3.3.50.33
284h RXSOFOVERRUNS Receive FIFO or DMA Start of Frame Overruns Register Section 17.3.3.50.34
288h RXMOFOVERRUNS Receive FIFO or DMA Middle of Frame Overruns Register Section 17.3.3.50.35
28Ch RXDMAOVERRUNS Receive DMA Overruns Register Section 17.3.3.50.36
