10.5.10.17 Pin Multiplexing Control 16 Register (PINMUX16)
Figure 10-34. Pin Multiplexing Control 16 Register (PINMUX16)
31 28 27 24 23 20 19 16
PINMUX16_31_28 PINMUX16_27_24 PINMUX16_23_20 PINMUX16_19_16
R/W-0 R/W-0 R/W-0 R/W-0
15 12 11 8 7 4 3 0
PINMUX16_15_12 PINMUX16_11_8 PINMUX16_7_4 PINMUX16_3_0
R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
(1)
The ZKB ball package is only available on the C6747 DSP; this package is not supported on the C6745 DSP.
(2)
The PTP pin package is only available on the C6745 DSP; this package is not supported on the C6747 DSP.
Table 10-38. Pin Multiplexing Control 16 Register (PINMUX16) Field Descriptions
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
31-28 PINMUX16_31_28 R11 40 EMA_A[9]/LCD_HSYNC/GP1[9] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[9]
2h Selects Function LCD_HSYNC
3h-7h Reserved
8h Selects Function GP1[9]
9h-Fh Reserved
27-24 PINMUX16_27_24 T11 39 EMA_A[8]/LCD_PCLK/GP1[8] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[8]
2h Selects Function LCD_PCLK
3h-7h Reserved
8h Selects Function GP1[8]
9h-Fh Reserved
23-20 PINMUX16_23_20 N10 37 EMA_A[7]/LCD_D[0]/GP1[7] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[7]
2h Selects Function LCD_D[0]
3h-7h Reserved
8h Selects Function GP1[7]
9h-Fh Reserved
19-16 PINMUX16_19_16 P10 36 EMA_A[6]/LCD_D[1]/GP1[6] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[6]
2h Selects Function LCD_D[1]
3h-7h Reserved
8h Selects Function GP1[6]
9h-Fh Reserved
