System Configuration (SYSCFG) Module
Table 10-37. Pin Multiplexing Control 15 Register (PINMUX15) Field Descriptions (continued)
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
19-16 PINMUX15_19_16 N14 — EMA_D[14]/UHPI_HD[14]/LCD_D[14]/GP0[14] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[14]
2h Selects Function UHPI_HD[14]
3h Reserved
4h Selects Function LCD_D[14]
5h-7h Reserved
8h Selects Function GP0[14]
9h-Fh Reserved
15-12 PINMUX15_15_12 N16 — EMA_D[13]/UHPI_HD[13]/LCD_D[13]/GP0[13] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[13]
2h Selects Function UHPI_HD[13]
3h Reserved
4h Selects Function LCD_D[13]
5h-7h Reserved
8h Selects Function GP0[13]
9h-Fh Reserved
11-8 PINMUX15_11_8 P14 — EMA_D[12]/UHPI_HD[12]/LCD_D[12]/GP0[12] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[12]
2h Selects Function UHPI_HD[12]
3h Reserved
4h Selects Function LCD_D[12]
5h-7h Reserved
8h Selects Function GP0[12]
9h-Fh Reserved
7-4 PINMUX15_7_4 P16 — EMA_D[11]/UHPI_HD[11]/LCD_D[11]/GP0[11] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[11]
2h Selects Function UHPI_HD[11]
3h Reserved
4h Selects Function LCD_D[11]
5h-7h Reserved
8h Selects Function GP0[11]
9h-Fh Reserved
3-0 PINMUX15_3_0 R14 — EMA_D[10]/UHPI_HD[10]/LCD_D[10]/GP0[10] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[10]
2h Selects Function UHPI_HD[10]
3h Reserved
4h Selects Function LCD_D[10]
5h-7h Reserved
8h Selects Function GP0[10]
9h-Fh Reserved
