System Configuration (SYSCFG) Module
10.5.10.20 Pin Multiplexing Control 19 Register (PINMUX19)
Figure 10-37. Pin Multiplexing Control 19 Register (PINMUX19)
31 16
Reserved
R/W-0
15 4 3 0
Reserved PINMUX19_3_0
R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
(1)
The ZKB ball package is only available on the C6747 DSP; this package is not supported on the C6745 DSP.
(2)
The PTP pin package is only available on the C6745 DSP; this package is not supported on the C6747 DSP.
Table 10-41. Pin Multiplexing Control 19 Register (PINMUX19) Field Descriptions
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
31-4 Reserved — — 0 Reserved
3-0 PINMUX19_3_0 N6 19 EMA_WAIT[0]/UHPI_HRDY/GP2[10] Control
0 Pin is 3-stated.
1h Selects Function EMA_WAIT[0]
2h Selects Function UHPI_HRDY
3h-7h Reserved
8h Selects Function GP2[10]
9h-Fh Reserved
