10.5.10.5 Pin Multiplexing Control 4 Register (PINMUX4)
Figure 10-22. Pin Multiplexing Control 4 Register (PINMUX4)
31 28 27 24 23 20 19 16
PINMUX4_31_28 PINMUX4_27_24 PINMUX4_23_20 PINMUX4_19_16
R/W-0 R/W-0 R/W-0 R/W-0
15 12 11 8 7 4 3 0
PINMUX4_15_12 PINMUX4_11_8 PINMUX4_7_4 PINMUX4_3_0
R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
(1)
The ZKB ball package is only available on the C6747 DSP; this package is not supported on the C6745 DSP.
(2)
The PTP pin package is only available on the C6745 DSP; this package is not supported on the C6747 DSP.
Table 10-26. Pin Multiplexing Control 4 Register (PINMUX4) Field Descriptions
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
31-28 PINMUX4_31_28 A12 — EMB_WE_DQM[3] Control
0 Pin is 3-stated.
1h Selects Function EMB_WE_DQM[3]
2h-Fh Reserved
27-24 PINMUX4_27_24 G15 — EMB_D[16] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[16]
2h-Fh Reserved
23-20 PINMUX4_23_20 H14 — EMB_D[17] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[17]
2h-Fh Reserved
19-16 PINMUX4_19_16 H15 — EMB_D[18] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[18]
2h-Fh Reserved
15-12 PINMUX4_15_12 J14 — EMB_D[19] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[19]
2h-Fh Reserved
11-8 PINMUX4_11_8 K13 — EMB_D[20] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[20]
2h-Fh Reserved
7-4 PINMUX4_7_4 K16 — EMB_D[21] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[21]
2h-Fh Reserved
3-0 PINMUX4_3_0 L14 — EMB_D[22] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[22]
2h-Fh Reserved
