Enhanced Capture (eCAP) Module
Table 13-3. ECAP Initialization for CAP Mode Delta Time, Rising Edge Trigger
Register Bit Value
ECCTL1 CAP1POL EC_RISING
ECCTL1 CAP2POL EC_RISING
ECCTL1 CAP3POL EC_RISING
ECCTL1 CAP4POL EC_RISING
ECCTL1 CTRRST1 EC_DELTA_MODE
ECCTL1 CTRRST2 EC_DELTA_MODE
ECCTL1 CTRRST3 EC_DELTA_MODE
ECCTL1 CTRRST4 EC_DELTA_MODE
ECCTL1 CAPLDEN EC_ENABLE
ECCTL1 PRESCALE EC_DIV1
ECCTL2 CAP_APWM EC_CAP_MODE
ECCTL2 CONT_ONESHT EC_CONTINUOUS
ECCTL2 SYNCO_SEL EC_SYNCO_DIS
ECCTL2 SYNCI_EN EC_DISABLE
ECCTL2 TSCTRSTOP EC_RUN
Example 13-3. Code Snippet for CAP Mode Delta Time, Rising Edge Trigger
// Code snippet for CAP mode Delta Time, Rising edge trigger
// Run Time ( e.g. CEVT1 triggered ISR call)
//==========================================
// Note: here Time-stamp directly represents the Period value.
Period4 = ECAPxRegs.CAP1; // Fetch Time-Stamp captured at T1
Period1 = ECAPxRegs.CAP2; // Fetch Time-Stamp captured at T2
Period2 = ECAPxRegs.CAP3; // Fetch Time-Stamp captured at T3
Period3 = ECAPxRegs.CAP4; // Fetch Time-Stamp captured at T4
