System Configuration (SYSCFG) Module
10.5.10.16 Pin Multiplexing Control 15 Register (PINMUX15)
Figure 10-33. Pin Multiplexing Control 15 Register (PINMUX15)
31 28 27 24 23 20 19 16
PINMUX15_31_28 PINMUX15_27_24 PINMUX15_23_20 PINMUX15_19_16
R/W-0 R/W-0 R/W-0 R/W-0
15 12 11 8 7 4 3 0
PINMUX15_15_12 PINMUX15_11_8 PINMUX15_7_4 PINMUX15_3_0
R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
(1)
The ZKB ball package is only available on the C6747 DSP; this package is not supported on the C6745 DSP.
(2)
The PTP pin package is only available on the C6745 DSP; this package is not supported on the C6747 DSP.
Table 10-37. Pin Multiplexing Control 15 Register (PINMUX15) Field Descriptions
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
31-28 PINMUX15_31_28 R9 30 EMA_A[1]/MMCSD_CLK/UHPI_HCNTL0/GP1[1] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[1]
2h Selects Function MMCSD_CLK
3h Reserved
4h Selects Function UHPI_HCNTL0
5h-7h Reserved
8h Selects Function GP1[1]
9h-Fh Reserved
27-24 PINMUX15_27_24 T9 29 EMA_A[0]/LCD_D[7]/GP1[0] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[0]
2h Selects Function LCD_D[7]
3h-7h Reserved
8h Selects Function GP1[0]
9h-Fh Reserved
23-20 PINMUX15_23_20 M16 — EMA_D[15]/UHPI_HD[15]/LCD_D[15]/GP0[15] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[15]
2h Selects Function UHPI_HD[15]
3h Reserved
4h Selects Function LCD_D[15]
5h-7h Reserved
8h Selects Function GP0[15]
9h-Fh Reserved
