System Configuration (SYSCFG) Module
Table 10-36. Pin Multiplexing Control 14 Register (PINMUX14) Field Descriptions (continued)
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
19-16 PINMUX14_19_16 N13 52 EMA_D[6]/MMCSD_DAT[6]/UHPI_HD[6]/GP0[6] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[6]
2h Selects Function MMCSD_DAT[6]
3h Reserved
4h Selects Function UHPI_HD[6]
5h-7h Reserved
8h Selects Function GP0[6]
9h-Fh Reserved
15-12 PINMUX14_15_12 N15 51 EMA_D[5]/MMCSD_DAT[5]/UHPI_HD[5]/GP0[5] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[5]
2h Selects Function MMCSD_DAT[5]
3h Reserved
4h Selects Function UHPI_HD[5]
5h-7h Reserved
8h Selects Function GP0[5]
9h-Fh Reserved
11-8 PINMUX14_11_8 P13 49 EMA_D[4]/MMCSD_DAT[4]/UHPI_HD[4]/GP0[4] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[4]
2h Selects Function MMCSD_DAT[4]
3h Reserved
4h Selects Function UHPI_HD[4]
5h-7h Reserved
8h Selects Function GP0[4]
9h-Fh Reserved
7-4 PINMUX14_7_4 P15 48 EMA_D[3]/MMCSD_DAT[3]/UHPI_HD[3]/GP0[3] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[3]
2h Selects Function MMCSD_DAT[3]
3h Reserved
4h Selects Function UHPI_HD[3]
5h-7h Reserved
8h Selects Function GP0[3]
9h-Fh Reserved
3-0 PINMUX14_3_0 R13 46 EMA_D[2]/MMCSD_DAT[2]/UHPI_HD[2]/GP0[2] Control
0 Pin is 3-stated.
1h Selects Function EMA_D[2]
2h Selects Function MMCSD_DAT[2]
3h Reserved
4h Selects Function UHPI_HD[2]
5h-7h Reserved
8h Selects Function GP0[2]
9h-Fh Reserved
