17.3.3.8 Transmit Interrupt Status (Masked) Register (TXINTSTATMASKED)
The transmit interrupt status (masked) register (TXINTSTATMASKED) is shown in Figure 17-46 and
described in Table 17-45.
Figure 17-46. Transmit Interrupt Status (Masked) Register (TXINTSTATMASKED)
31 16
Reserved
R-0
15 8
Reserved
R-0
7 6 5 4 3 2 1 0
TX7PEND TX6PEND TX5PEND TX4PEND TX3PEND TX2PEND TX1PEND TX0PEND
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 17-45. Transmit Interrupt Status (Masked) Register (TXINTSTATMASKED) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reserved
7 TX7PEND 0-1 TX7PEND masked interrupt read
6 TX6PEND 0-1 TX6PEND masked interrupt read
5 TX5PEND 0-1 TX5PEND masked interrupt read
4 TX4PEND 0-1 TX4PEND masked interrupt read
3 TX3PEND 0-1 TX3PEND masked interrupt read
2 TX2PEND 0-1 TX2PEND masked interrupt read
1 TX1PEND 0-1 TX1PEND masked interrupt read
0 TX0PEND 0-1 TX0PEND masked interrupt read
