Texas Instruments TMS320C6745 DSP - Pin Multiplexing Control 6 Register (PINMUX6); Pin Multiplexing Control 6 Register (PINMUX6) Field Descriptions

www.ti.com SYSCFG Registers
199
SPRUH91D–March 2013–Revised September 2016
Submit Documentation Feedback
Copyright © 2013–2016, Texas Instruments Incorporated
System Configuration (SYSCFG) Module
10.5.10.7 Pin Multiplexing Control 6 Register (PINMUX6)
Figure 10-24. Pin Multiplexing Control 6 Register (PINMUX6)
31 28 27 24 23 20 19 16
PINMUX6_31_28 PINMUX6_27_24 PINMUX6_23_20 PINMUX6_19_16
R/W-0 R/W-0 R/W-0 R/W-0
15 12 11 8 7 4 3 0
PINMUX6_15_12 PINMUX6_11_8 PINMUX6_7_4 PINMUX6_3_0
R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
(1)
The ZKB ball package is only available on the C6747 DSP; this package is not supported on the C6745 DSP.
(2)
The PTP pin package is only available on the C6745 DSP; this package is not supported on the C6747 DSP.
Table 10-28. Pin Multiplexing Control 6 Register (PINMUX6) Field Descriptions
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
31-28 PINMUX6_31_28 E16 76 EMB_D[14]/GP6[14] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[14]
2h-7h Reserved
8h Selects Function GP6[14]
9h-Fh Reserved
27-24 PINMUX6_27_24 E13 78 EMB_D[13]/GP6[13] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[13]
2h-7h Reserved
8h Selects Function GP6[13]
9h-Fh Reserved
23-20 PINMUX6_23_20 D16 79 EMB_D[12]/GP6[12] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[12]
2h-7h Reserved
8h Selects Function GP6[12]
9h-Fh Reserved
19-16 PINMUX6_19_16 D15 80 EMB_D[11]/GP6[11] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[11]
2h-7h Reserved
8h Selects Function GP6[11]
9h-Fh Reserved
15-12 PINMUX6_15_12 D14 82 EMB_D[10]/GP6[10] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[10]
2h-7h Reserved
8h Selects Function GP6[10]
9h-Fh Reserved
