External Memory Interface A (EMIFA)
18.4.22 NAND Flash 4-Bit ECC Error Value Register 1 (NANDERRVAL1)
The NAND Flash 4-bit ECC error value register 1 (NANDERRVAL1) is shown in Figure 18-52 and
described in Table 18-70.
Figure 18-52. NAND Flash 4-Bit ECC Error Value Register 1 (NANDERRVAL1)
31 26 25 16
Reserved 4BITECCERRVAL2
R-0 R/W-0
15 10 9 0
Reserved 4BITECCERRVAL1
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 18-70. NAND Flash 4-Bit ECC Error Value Register 1 (NANDERRVAL1) Field Descriptions
Bit Field Value Description
31-26 Reserved 0 Reserved
25-16 4BITECCERRVAL2 0-3FFh Calculated 4-bit ECC Error Value 2.
15-10 Reserved 0 Reserved
9-0 4BITECCERRVAL1 0-3FFh Calculated 4-bit ECC Error Value 1.
18.4.23 NAND Flash 4-Bit ECC Error Value Register 2 (NANDERRVAL2)
The NAND Flash 4-bit ECC error value register 2 (NANDERRVAL2) is shown in Figure 18-53 and
described in Table 18-71.
Figure 18-53. NAND Flash 4-Bit ECC Error Value Register 2 (NANDERRVAL2)
31 26 25 16
Reserved 4BITECCERRVAL4
R-0 R/W-0
15 10 9 0
Reserved 4BITECCERRVAL3
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 18-71. NAND Flash 4-Bit ECC Error Value Register 2 (NANDERRVAL2) Field Descriptions
Bit Field Value Description
31-26 Reserved 0 Reserved
25-16 4BITECCERRVAL4 0-3FFh Calculated 4-bit ECC Error Value 4.
15-10 Reserved 0 Reserved
9-0 4BITECCERRVAL3 0-3FFh Calculated 4-bit ECC Error Value 3.
