EMAC/MDIO Module
17.3.3.7 Transmit Interrupt Status (Unmasked) Register (TXINTSTATRAW)
The transmit interrupt status (unmasked) register (TXINTSTATRAW) is shown in Figure 17-45 and
described in Table 17-44.
Figure 17-45. Transmit Interrupt Status (Unmasked) Register (TXINTSTATRAW)
31 16
Reserved
R-0
15 8
Reserved
R-0
7 6 5 4 3 2 1 0
TX7PEND TX6PEND TX5PEND TX4PEND TX3PEND TX2PEND TX1PEND TX0PEND
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 17-44. Transmit Interrupt Status (Unmasked) Register (TXINTSTATRAW) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reserved
7 TX7PEND 0-1 TX7PEND raw interrupt read (before mask)
6 TX6PEND 0-1 TX6PEND raw interrupt read (before mask)
5 TX5PEND 0-1 TX5PEND raw interrupt read (before mask)
4 TX4PEND 0-1 TX4PEND raw interrupt read (before mask)
3 TX3PEND 0-1 TX3PEND raw interrupt read (before mask)
2 TX2PEND 0-1 TX2PEND raw interrupt read (before mask)
1 TX1PEND 0-1 TX1PEND raw interrupt read (before mask)
0 TX0PEND 0-1 TX0PEND raw interrupt read (before mask)
