www.ti.com eQEP Registers
435
SPRUH91D–March 2013–Revised September 2016
Submit Documentation Feedback
Copyright © 2013–2016, Texas Instruments Incorporated
Enhanced Quadrature Encoder Pulse (eQEP) Module
15.3.24 eQEP Capture Period Latch Register (QCPRDLAT)
Figure 15-44. eQEP Capture Period Latch Register (QCPRDLAT)
15 0
QCPRDLAT
R/W
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 15-26. eQEP Capture Period Latch Register (QCPRDLAT) Field Descriptions
Bits Name Value Description
15-0 QCPRDLAT 0-FFFFh eQEP capture period value can be latched into this register on two events viz., unit timeout
event, reading the eQEP position counter.
15.3.25 eQEP Revision ID Register (REVID)
Figure 15-45. eQEP Revision ID Register (REVID)
31 0
REV
R-44D3 1103h
LEGEND: R = Read only; -n = value after reset
Table 15-27. eQEP Revision ID Register (REVID) Field Descriptions
Bits Name Value Description
31-0 REV 44D3 1103h eQEP revision ID
