General-Purpose Input/Output (GPIO)
Table 20-2. GPIO Registers (continued)
Offset Acronym Register Description Section
GPIO Banks 6 and 7
88h DIR67 GPIO Banks 6 and 7 Direction Register Section 20.3.3
8Ch OUT_DATA67 GPIO Banks 6 and 7 Output Data Register Section 20.3.4
90h SET_DATA67 GPIO Banks 6 and 7 Set Data Register Section 20.3.5
94h CLR_DATA67 GPIO Banks 6 and 7 Clear Data Register Section 20.3.6
98h IN_DATA67 GPIO Banks 6 and 7 Input Data Register Section 20.3.7
9Ch SET_RIS_TRIG67 GPIO Banks 6 and 7 Set Rising Edge Interrupt Register Section 20.3.8
A0h CLR_RIS_TRIG67 GPIO Banks 6 and 7 Clear Rising Edge Interrupt Register Section 20.3.9
A4h SET_FAL_TRIG67 GPIO Banks 6 and 7 Set Falling Edge Interrupt Register Section 20.3.10
A8h CLR_FAL_TRIG67 GPIO Banks 6 and 7 Clear Falling Edge Interrupt Register Section 20.3.11
ACh INTSTAT67 GPIO Banks 6 and 7 Interrupt Status Register Section 20.3.12
GPIO Bank 8
B0h DIR8 GPIO Bank 8 Direction Register Section 20.3.3
B4h OUT_DATA8 GPIO Bank 8 Output Data Register Section 20.3.4
B8h SET_DATA8 GPIO Bank 8 Set Data Register Section 20.3.5
BCh CLR_DATA8 GPIO Bank 8 Clear Data Register Section 20.3.6
C0h IN_DATA8 GPIO Bank 8 Input Data Register Section 20.3.7
C4h SET_RIS_TRIG8 GPIO Bank 8 Set Rising Edge Interrupt Register Section 20.3.8
C8h CLR_RIS_TRIG8 GPIO Bank 8 Clear Rising Edge Interrupt Register Section 20.3.9
CCh SET_FAL_TRIG8 GPIO Bank 8 Set Falling Edge Interrupt Register Section 20.3.10
D0h CLR_FAL_TRIG8 GPIO Bank 8 Clear Falling Edge Interrupt Register Section 20.3.11
D4h INTSTAT8 GPIO Bank 8 Interrupt Status Register Section 20.3.12
20.3.1 Revision ID Register (REVID)
The revision ID register (REVID) contains the peripheral version information. REVID is shown in
Figure 20-2 and described in Table 20-3.
Figure 20-2. Revision ID Register (REVID)
31 0
REV
R-4483 0105h
LEGEND: R = Read only; -n = value after reset
Table 20-3. Revision ID Register (REVID) Field Descriptions
Bit Field Value Description
31-0 REV 4483 0105h Peripheral Revision
