External Memory Interface A (EMIFA)
Since the value of the W_SETUP/R_SETUP, W_STROBE/R_STROBE, W_HOLD/R_HOLD, and TA fields
are equal to EMIFA clock cycles minus 1 cycle, the CE3CFG should be configured as in Table 18-39. In
this example, the EMA_WAIT signal is not implemented; therefore, the asynchronous wait cycle
configuration register (AWCC) does not need to be programmed.
Table 18-39. Configuring CE3CFG for TC5516100FT-12 Example
Parameter Setting
SS Select Strobe mode.
• SS = 0. Places EMIFA in Normal Mode.
EW Extended Wait mode enable.
• EW = 0. Disabled Extended wait mode.
W_SETUP/R_SETUP Read/Write setup widths.
• W_SETUP = 0
• R_SETUP = 0
W_STROBE/R_STROBE Read/Write strobe widths.
• W_STROBE = 0
• R_STROBE = 0
W_HOLD/R_HOLD Read/Write hold widths.
• W_HOLD = 0
• R_HOLD = 0
TA Minimum turnaround time.
• TA = 0
ASIZE Asynchronous Device Bus Width.
• ASIZE = 1, select a 16-bit data bus width
18.3.2.3 Interfacing to NAND Flash
The following example explains how to interface the EMIFA to the Hynix HY27UA081G1M NAND Flash
device.
18.3.2.3.1 Margin Requirements
The Flash interface is typically a low-performance interface compared to synchronous memory interfaces,
high-speed asynchronous memory interfaces, and high-speed FIFO interfaces. For this reason, this
example gives little attention to minimizing the amount of margin required when programming the
asynchronous timing parameters. The approach used requires approximately 10 ns of margin on all
parameters, which is not significant for a 100-ns read or write cycle. For additional details on minimizing
the amount of margin, see the ASRAM example given in Section 18.3.2.2.
Table 18-40. Recommended Margins
Timing Parameter Recommended Margin
Output Setup 10 nS
Output Hold 10 nS
Input Setup 10 nS
Input Hold 10 nS
