General-Purpose Input/Output (GPIO)
Figure 20-33. GPIO Bank 8 Set Rise Trigger Register (SET_RIS_TRIG8)
31 16
Reserved
R/W-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP8P15 GP8P14 GP8P13 GP8P12 GP8P11 GP8P10 GP8P9 GP8P8 GP8P7 GP8P6 GP8P5 GP8P4 GP8P3 GP8P2 GP8P1 GP8P0
R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
Table 20-10. GPIO Set Rising Edge Trigger Interrupt Register (SET_RIS_TRIG n) Field Descriptions
Bit Field Value Description
31-0 GPjPk Enable rising edge trigger interrupt detection on GPk[j]. Reading the GPkPj bit in either
SET_RIS_TRIGn or CLR_RIS_TRIGn always returns an indication of whether the rising edge interrupt
generation function is enabled for pin GPk[j]. Therefore, this bit will be one in both registers if the
function is enabled, and zero in both registers if the function is disabled.
0 No effect.
1 Interrupt is caused by a low-to-high transition on GPk[j].
