System Configuration (SYSCFG) Module
10.5.10.12 Pin Multiplexing Control 11 Register (PINMUX11)
Figure 10-29. Pin Multiplexing Control 11 Register (PINMUX11)
31 28 27 24 23 20 19 16
PINMUX11_31_28 PINMUX11_27_24 PINMUX11_23_20 PINMUX11_19_16
R/W-0 R/W-0 R/W-0 R/W-0
15 12 11 8 7 4 3 0
PINMUX11_15_12 PINMUX11_11_8 PINMUX11_7_4 PINMUX11_3_0
R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
(1)
The ZKB ball package is only available on the C6747 DSP; this package is not supported on the C6745 DSP.
(2)
The PTP pin package is only available on the C6745 DSP; this package is not supported on the C6747 DSP.
Table 10-33. Pin Multiplexing Control 11 Register (PINMUX11) Field Descriptions
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
31-28 PINMUX11_31_28 K4 163 AFSX1/EPWMSYNCI/EPWMSYNC0/GP4[10] Control
0 Pin is 3-stated.
1h Selects Function AFSX1
2h Selects Function EPWMSYNCI
3h Reserved
4h Selects Function EPWMSYNC0
5h-7h Reserved
8h Selects Function GP4[10]
9h-Fh Reserved
27-24 PINMUX11_27_24 K3 162 ACLKX1/EPWM0A/GP3[15] Control
0 Pin is 3-stated.
1h Selects Function ACLKX1
2h Selects Function EPWM0A
3h-7h Reserved
8h Selects Function GP3[15]
9h-Fh Reserved
23-20 PINMUX11_23_20 K2 160 AHCLKX1/EPWM0B/GP3[14] Control
0 Pin is 3-stated.
1h Selects Function AHCLKX1
2h Selects Function EPWM0B
3h-7h Reserved
8h Selects Function GP3[14]
9h-Fh Reserved
19-16 PINMUX11_19_16 A5 124 AXR0[11]/AXR2[0]/GP3[11] Control
0 Pin is 3-stated.
1h Selects Function AXR0[11]
2h-3h Reserved
4h Selects Function AXR2[0]
5h-7h Reserved
8h Selects Function GP3[11]
9h-Fh Reserved
