System Configuration (SYSCFG) Module
Table 10-33. Pin Multiplexing Control 11 Register (PINMUX11) Field Descriptions (continued)
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
15-12 PINMUX11_15_12 D6 123 UART1_TXD/AXR0[10]/GP3[10] Control
0 Pin is 3-stated.
1h Selects Function UART1_TXD
2h Selects Function AXR0[10]
3h-7h Reserved
8h Selects Function GP3[10]
9h-Fh Reserved
11-8 PINMUX11_11_8 C6 122 UART1_RXD/AXR0[9]/GP3[9] Control
0 Pin is 3-stated.
1h Selects Function UART1_RXD
2h Selects Function AXR0[9]
3h-7h Reserved
8h Selects Function GP3[9]
9h-Fh Reserved
7-4 PINMUX11_7_4 B6 121 AXR0[8]/MDIO_D/GP3[8] Control
0 Pin is 3-stated.
1h Selects Function AXR0[8]
2h Selects Function MDIO_D
3h-7h Reserved
8h Selects Function GP3[8]
9h-Fh Reserved
3-0 PINMUX11_3_0 A6 120 AXR0[7]/MDIO_CLK/GP3[7] Control
0 Pin is 3-stated.
1h Selects Function AXR0[7]
2h Selects Function MDIO_CLK
3h-7h Reserved
8h Selects Function GP3[7]
9h-Fh Reserved
