Enhanced High-Resolution Pulse-Width Modulator (eHRPWM)
14.4.6.2 Trip-Zone Control Register (TZCTL)
The trip-zone control register (TZCTL) is shown in Figure 14-82 and described in Table 14-73.
Figure 14-82. Trip-Zone Control Register (TZCTL)
15 4 3 2 1 0
Reserved TZB TZA
R-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-73. Trip-Zone Control Register (TZCTL) Field Descriptions
Bits Name Value Description
15–4 Reserved 0 Reserved
3–2 TZB 0-3h When a trip event occurs the following action is taken on output EPWMxB. Which trip-zone pins can
cause an event is defined in the TZSEL register (Section 14.4.6.1).
0 High impedance (EPWMxB = High-impedance state)
1h Force EPWMxB to a high state
2h Force EPWMxB to a low state
3h Do nothing, no action is taken on EPWMxB.
1–0 TZA 0-3h When a trip event occurs the following action is taken on output EPWMxA. Which trip-zone pins can
cause an event is defined in the TZSEL register (Section 14.4.6.1).
0 High impedance (EPWMxA = High-impedance state)
1h Force EPWMxA to a high state
2h Force EPWMxA to a low state
3h Do nothing, no action is taken on EPWMxA.
14.4.6.3 Trip-Zone Enable Interrupt Register (TZEINT)
The trip-zone enable interrupt register (TZEINT) is shown in Figure 14-83 and described in Table 14-74.
Figure 14-83. Trip-Zone Enable Interrupt Register (TZEINT)
15 3 2 1 0
Reserved OST CBC Rsvd
R-0 R/W-0 R/W-0 R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-74. Trip-Zone Enable Interrupt Register (TZEINT) Field Descriptions
Bits Name Value Description
15-3 Reserved 0 Reserved
2 OST Trip-zone One-Shot Interrupt Enable
0 Disable one-shot interrupt generation
1 Enable Interrupt generation; a one-shot trip event will cause a EPWMxTZINT interrupt.
1 CBC Trip-zone Cycle-by-Cycle Interrupt Enable
0 Disable cycle-by-cycle interrupt generation.
1 Enable interrupt generation; a cycle-by-cycle trip event will cause an EPWMxTZINT interrupt.
0 Reserved 0 Reserved
