General-Purpose Input/Output (GPIO)
20.3.2 GPIO Interrupt Per-Bank Enable Register (BINTEN)
The GPIO interrupt per-bank enable register (BINTEN) is shown in Figure 20-3 and described in Table 20-
4. For information on which GPIO signals are associated with each bank, see Table 20-1. Note that the
bits in BINTEN control both the interrupt and EDMA events.
Figure 20-3. GPIO Interrupt Per-Bank Enable Register (BINTEN)
31 16
Reserved
R-0
15 9 8 7 6 5 4 3 2 1 0
Reserved EN8 EN7 EN6 EN5 EN4 EN3 EN2 EN1 EN0
R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 20-4. GPIO Interrupt Per-Bank Enable Register (BINTEN) Field Descriptions
Bit Field Value Description
31-9 Reserved 0 Reserved
8 EN8 Bank 8 interrupt enable is used to disable or enable the bank 8 interrupts (events from GP8[15-0]).
0 Bank 8 interrupts are disabled.
1 Bank 8 interrupts are enabled.
7 EN7 Bank 7 interrupt enable is used to disable or enable the bank 7 interrupts (events from GP7[15-0]).
0 Bank 7 interrupts are disabled.
1 Bank 7 interrupts are enabled.
6 EN6 Bank 6 interrupt enable is used to disable or enable the bank 6 interrupts (events from GP6[15-0]).
0 Bank 6 interrupts are disabled.
1 Bank 6 interrupts are enabled.
5 EN5 Bank 5 interrupt enable is used to disable or enable the bank 5 interrupts (events from GP5[15-0]).
0 Bank 5 interrupts are disabled.
1 Bank 5 interrupts are enabled.
4 EN4 Bank 4 interrupt enable is used to disable or enable the bank 4 interrupts (events from GP4[15-0]).
0 Bank 4 interrupts are disabled.
1 Bank 4 interrupts are enabled.
3 EN3 Bank 3 interrupt enable is used to disable or enable the bank 3 interrupts (events from GP3[15-0])
0 Bank 3 interrupts are disabled.
1 Bank 3 interrupts are enabled.
2 EN2 Bank 2 interrupt enable is used to disable or enable the bank 2 interrupts (events from GP2[15-0]).
0 Bank 2 interrupts are disabled.
1 Bank 2 interrupts are enabled.
1 EN1 Bank 1 interrupt enable is used to disable or enable the bank 1 interrupts (events from GP1[15-0]).
0 Bank 1 interrupts are disabled.
1 Bank 1 interrupts are enabled.
0 EN0 Bank 0 interrupt enable is used to disable or enable the bank 0 interrupts (events from GP0[15-0]).
0 Bank 0 interrupts are disabled.
1 Bank 0 interrupts are enabled.
