Enhanced High-Resolution Pulse-Width Modulator (eHRPWM)
14.4.7.3 Event-Trigger Flag Register (ETFLG)
The event-trigger flag register (ETFLG) is shown in Figure 14-89 and described in Table 14-81.
Figure 14-89. Event-Trigger Flag Register (ETFLG)
15 1 0
Reserved INT
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 14-81. Event-Trigger Flag Register (ETFLG) Field Descriptions
Bits Name Value Description
15-1 Reserved 0 Reserved
0 INT Latched ePWM Interrupt (EPWMx_INT) Status Flag
0 Indicates no event occurred
1 Indicates that an ePWMx interrupt (EWPMx_INT) was generated. No further interrupts will be generated
until the flag bit is cleared. Up to one interrupt can be pending while the ETFLG[INT] bit is still set. If an
interrupt is pending, it will not be generated until after the ETFLG[INT] bit is cleared. Refer to Figure 14-
42.
14.4.7.4 Event-Trigger Clear Register (ETCLR)
The event-trigger clear register (ETCLR) is shown in Figure 14-90 and described in Table 14-82.
Figure 14-90. Event-Trigger Clear Register (ETCLR)
15 1 0
Reserved INT
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 14-82. Event-Trigger Clear Register (ETCLR) Field Descriptions
Bits Name Value Description
15-1 Reserved 0 Reserved
0 INT ePWM Interrupt (EPWMx_INT) Flag Clear Bit
0 Writing a 0 has no effect. Always reads back a 0.
1 Clears the ETFLG[INT] flag bit and enable further interrupts pulses to be generated.
