Enhanced Direct Memory Access (EDMA3) Controller
16.4.3.6.7 Source Active Count Reload Register (SACNTRLD)
The source active count reload register (SACNTRLD) is shown in Figure 16-97 and described in
Table 16-77.
Figure 16-97. Source Active Count Reload Register (SACNTRLD)
31 16
Reserved
R-0
15 0
ACNTRLD
R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 16-77. Source Active Count Reload Register (SACNTRLD) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reserved
15-0 ACNTRLD 0-FFFFh A-count reload value. Represents the originally programmed value of ACNT. The reload value is
used to reinitialize ACNT after each array is serviced.
16.4.3.6.8 Source Active Source Address B-Reference Register (SASRCBREF)
The source active source address B-reference register (SASRCBREF) is shown in Figure 16-98 and
described in Table 16-78.
Figure 16-98. Source Active Source Address B-Reference Register (SASRCBREF)
31 0
SADDRBREF
R-0
LEGEND: R = Read only; -n = value after reset
Table 16-78. Source Active Source Address B-Reference Register (SASRCBREF) Field Descriptions
Bit Field Value Description
31-0 SADDRBREF 0-FFFF FFFFh Source address B-reference. Represents the starting address for the array currently being
Read.
