Inter-Integrated Circuit (I2C) Module
22.3.2 I2C Interrupt Mask Register (ICIMR)
The I2C interrupt mask register (ICIMR) is used to individually enable or disable I2C interrupt requests.
ICIMR is shown in Figure 22-14 and described Table 22-6.
Figure 22-14. I2C Interrupt Mask Register (ICIMR)
31 8
Reserved
R-0
7 6 5 4 3 2 1 0
Reserved AAS SCD ICXRDY ICRRDY ARDY NACK AL
R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 22-6. I2C Interrupt Mask Register (ICIMR) Field Descriptions
Bit Field Value Description
31-7 Reserved 0 These reserved bit locations are always read as zeros. A value written to this field has no effect.
6 AAS Address-as-slave interrupt enable bit.
0 Interrupt request is disabled.
1 Interrupt request is enabled.
5 SCD Stop condition detected interrupt enable bit.
0 Interrupt request is disabled.
1 Interrupt request is enabled.
4 ICXRDY Transmit-data-ready interrupt enable bit.
0 Interrupt request is disabled.
1 Interrupt request is enabled.
3 ICRRDY Receive-data-ready interrupt enable bit.
0 Interrupt request is disabled.
1 Interrupt request is enabled.
2 ARDY Register-access-ready interrupt enable bit.
0 Interrupt request is disabled.
1 Interrupt request is enabled.
1 NACK No-acknowledgment interrupt enable bit.
0 Interrupt request is disabled.
1 Interrupt request is enabled.
0 AL Arbitration-lost interrupt enable bit
0 Interrupt request is disabled.
1 Interrupt request is enabled.
