EMAC/MDIO Module
17.3.3.13 Receive Interrupt Status (Unmasked) Register (RXINTSTATRAW)
The receive interrupt status (unmasked) register (RXINTSTATRAW) is shown in Figure 17-51 and
described in Table 17-50.
Figure 17-51. Receive Interrupt Status (Unmasked) Register (RXINTSTATRAW)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8
RX7THRESHPEND RX6THRESHPEND RX5THRESHPEND RX4THRESHPEND RX3THRESHPEND RX2THRESHPEND RX1THRESHPEND RX0THRESHPEND
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
7 6 5 4 3 2 1 0
RX7PEND RX6PEND RX5PEND RX4PEND RX3PEND RX2PEND RX1PEND RX0PEND
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 17-50. Receive Interrupt Status (Unmasked) Register (RXINTSTATRAW) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reserved
15 RX7THRESHPEND 0-1 RX7THRESHPEND raw interrupt read (before mask)
14 RX6THRESHPEND 0-1 RX6THRESHPEND raw interrupt read (before mask)
13 RX5THRESHPEND 0-1 RX5THRESHPEND raw interrupt read (before mask)
12 RX4THRESHPEND 0-1 RX4THRESHPEND raw interrupt read (before mask)
11 RX3THRESHPEND 0-1 RX3THRESHPEND raw interrupt read (before mask)
10 RX2THRESHPEND 0-1 RX2THRESHPEND raw interrupt read (before mask)
9 RX1THRESHPEND 0-1 RX1THRESHPEND raw interrupt read (before mask)
8 RX0THRESHPEND 0-1 RX0THRESHPEND raw interrupt read (before mask)
7 RX7PEND 0-1 RX7PEND raw interrupt read (before mask)
6 RX6PEND 0-1 RX6PEND raw interrupt read (before mask)
5 RX5PEND 0-1 RX5PEND raw interrupt read (before mask)
4 RX4PEND 0-1 RX4PEND raw interrupt read (before mask)
3 RX3PEND 0-1 RX3PEND raw interrupt read (before mask)
2 RX2PEND 0-1 RX2PEND raw interrupt read (before mask)
1 RX1PEND 0-1 RX1PEND raw interrupt read (before mask)
0 RX0PEND 0-1 RX0PEND raw interrupt read (before mask)
