General-Purpose Input/Output (GPIO)
20.3.11 GPIO Clear Falling Edge Interrupt Registers (CLR_FAL_TRIGn)
The GPIO clear falling edge trigger interrupt register (CLR_FAL_TRIGn) disables the falling edge trigger
on the GPIO pin to generate a GPIO interrupt. The GPIO clear falling edge interrupt register
(CLR_FAL_TRIG01) is shown in Figure 20-44, CLR_FAL_TRIG23 is shown in Figure 20-45,
CLR_FAL_TRIG45 is shown in Figure 20-46, CLR_FAL_TRIG67 is shown in Figure 20-47,
CLR_FAL_TRIG8 is shown in Figure 20-48, and described in Table 20-13. See Table 20-1 to determine
the CLR_FAL_TRIGn bit associated with each GPIO bank and pin number.
Figure 20-44. GPIO Banks 0 and 1 Clear Rise Trigger Register (CLR_FAL_TRIG01)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GP1P15 GP1P14 GP1P13 GP1P12 GP1P11 GP1P10 GP1P9 GP1P8 GP1P7 GP1P6 GP1P5 GP1P4 GP1P3 GP1P2 GP1P1 GP1P0
R/W-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP0P15 GP0P14 GP0P13 GP0P12 GP0P11 GP0P10 GP0P9 GP0P8 GP0P7 GP0P6 GP0P5 GP0P4 GP0P3 GP0P2 GP0P1 GP0P0
R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
Figure 20-45. GPIO Banks 2 and 3 Clear Rise Trigger Register (CLR_FAL_TRIG23)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GP3P15 GP3P14 GP3P13 GP3P12 GP3P11 GP3P10 GP3P9 GP3P8 GP3P7 GP3P6 GP3P5 GP3P4 GP3P3 GP3P2 GP3P1 GP3P0
R/W-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP2P15 GP2P14 GP2P13 GP2P12 GP2P11 GP2P10 GP2P9 GP2P8 GP2P7 GP2P6 GP2P5 GP2P4 GP2P3 GP2P2 GP2P1 GP2P0
R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
Figure 20-46. GPIO Banks 4 and 5 Clear Rise Trigger Register (CLR_FAL_TRIG45)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GP5P15 GP5P14 GP5P13 GP5P12 GP5P11 GP5P10 GP5P9 GP5P8 GP5P7 GP5P6 GP5P5 GP5P4 GP5P3 GP5P2 GP5P1 GP5P0
R/W-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP4P15 GP4P14 GP4P13 GP4P12 GP4P11 GP4P10 GP4P9 GP4P8 GP4P7 GP4P6 GP4P5 GP4P4 GP4P3 GP4P2 GP4P1 GP4P0
R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
Figure 20-47. GPIO Banks 6 and 7 Clear Rise Trigger Register (CLR_FAL_TRIG67)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GP7P15 GP7P14 GP7P13 GP7P12 GP7P11 GP7P10 GP7P9 GP7P8 GP7P7 GP7P6 GP7P5 GP7P4 GP7P3 GP7P2 GP7P1 GP7P0
R/W-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP6P15 GP6P14 GP6P13 GP6P12 GP6P11 GP6P10 GP6P9 GP6P8 GP6P7 GP6P6 GP6P5 GP6P4 GP6P3 GP6P2 GP6P1 GP6P0
R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
