EMAC/MDIO Module
17.3.3.3 Transmit Teardown Register (TXTEARDOWN)
The transmit teardown register (TXTEARDOWN) is shown in Figure 17-41 and described in Table 17-40.
Figure 17-41. Transmit Teardown Register (TXTEARDOWN)
31 16
Reserved
R-0
15 3 2 0
Reserved TXTDNCH
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 17-40. Transmit Teardown Register (TXTEARDOWN) Field Descriptions
Bit Field Value Description
31-3 Reserved 0 Reserved
2-0 TXTDNCH 0-7h Transmit teardown channel. The transmit channel teardown is commanded by writing the encoded
value of the transmit channel to be torn down. The teardown register is read as 0.
0 Teardown transmit channel 0
1h Teardown transmit channel 1
2h Teardown transmit channel 2
3h Teardown transmit channel 3
4h Teardown transmit channel 4
5h Teardown transmit channel 5
6h Teardown transmit channel 6
7h Teardown transmit channel 7
