General-Purpose Input/Output (GPIO)
Figure 20-53. GPIO Bank 8 Interrupt Status Register (INTSTAT8)
31 16
Reserved
R/W1C-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
GP8P15 GP8P14 GP8P13 GP8P12 GP8P11 GP8P10 GP8P9 GP8P8 GP8P7 GP8P6 GP8P5 GP8P4 GP8P3 GP8P2 GP8P1 GP8P0
R/W1C-0
LEGEND: R/W = Read/Write; W1C = Write 1 to clear bit (writing 0 has no effect); -n = value after reset
Table 20-14. GPIO Interrupt Status Register (INTSTATn) Field Descriptions
Bit Field Value Description
31-0 GPkPj Interrupt status of GPk[j]. The GPkPj bit is used to monitor pending GPIO interrupts on pin j of GPIO bank
k. Write a 1 to the GPkPj bit to clear the status bit; a write of 0 has no effect.
0 No pending interrupt on GPk[j].
1 Pending interrupt on GPk[j].
