Enhanced Direct Memory Access (EDMA3) Controller
16.2.6.1 DMA Channel to PaRAM Mapping
The mapping between the DMA channel numbers and the PaRAM sets is a fixed, one-to-one mapping
(see Table 16-5). In other words, channel (event) 0 is mapped to PaRAM set 0, channel (event 1) is
mapped to PaRAM set 1, etc. So, for example, in order to program a transfer for event number 3, DMA
channel 3 is associated with PaRAM set number 3 and you need to program this PaRAM set for
configuring transfers associated with event number 3. See your device-specific data manual for the
addresses of the PaRAM set entries.
Table 16-5. EDMA3 DMA Channel to PaRAM Mapping
PaRAM Set Number Mapping
PaRAM Set 0 DMA Channel 0/Reload/QDMA
PaRAM Set 1 DMA Channel 1/Reload/QDMA
PaRAM Set 2 DMA Channel 2/Reload/QDMA
PaRAM Set 3 DMA Channel 3/Reload/QDMA
PaRAM Set 4 DMA Channel 4/Reload/QDMA
PaRAM Set 5 DMA Channel 5/Reload/QDMA
PaRAM Set 6 DMA Channel 6/Reload/QDMA
PaRAM Set 7 DMA Channel 7/Reload/QDMA
PaRAM Set 8 DMA Channel 8/Reload/QDMA
PaRAM Set 9 DMA Channel 9/Reload/QDMA
PaRAM Set 10 DMA Channel 10/Reload/QDMA
PaRAM Set 11 DMA Channel 11/Reload/QDMA
PaRAM Set 12 DMA Channel 12/Reload/QDMA
PaRAM Set 13 DMA Channel 13/Reload/QDMA
PaRAM Set 14 DMA Channel 14/Reload/QDMA
PaRAM Set 15 DMA Channel 15/Reload/QDMA
PaRAM Set 16 DMA Channel 16/Reload/QDMA
... ...
PaRAM Set 30 DMA Channel 30/Reload/QDMA
PaRAM Set 31 DMA Channel 31/Reload/QDMA
PaRAM Set 32 Reload/QDMA
PaRAM Set 33 Reload/QDMA
... ...
PaRAM Set n - 2 Reload/QDMA
PaRAM Set n - 1 Reload/QDMA
PaRAM Set n Reload/QDMA
