Enhanced High-Resolution Pulse-Width Modulator (eHRPWM)
14.4.4.2 Dead-Band Generator Rising Edge Delay Register (DBRED)
The dead-band generator rising edge delay register (DBRED) is shown in Figure 14-78 and described in
Table 14-68.
Figure 14-78. Dead-Band Generator Rising Edge Delay Register (DBRED)
15 10 9 0
Reserved DEL
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-68. Dead-Band Generator Rising Edge Delay Register (DBRED) Field Descriptions
Bits Name Value Description
15-10 Reserved 0 Reserved
9-0 DEL 0-3FFh Rising Edge Delay Count. 10-bit counter.
14.4.4.3 Dead-Band Generator Falling Edge Delay Register (DBFED)
The dead-band generator falling edge delay register (DBFED) is shown in Figure 14-79 and described in
Table 14-69.
Figure 14-79. Dead-Band Generator Falling Edge Delay Register (DBFED)
15 10 9 0
Reserved DEL
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-69. Dead-Band Generator Falling Edge Delay Register (DBFED) Field Descriptions
Bits Name Value Description
15-10 Reserved 0 Reserved
9-0 DEL 0-3FFh Falling Edge Delay Count. 10-bit counter
