System Configuration (SYSCFG) Module
Table 10-32. Pin Multiplexing Control 10 Register (PINMUX10) Field Descriptions (continued)
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
19-16 PINMUX10_19_16 A7 115 AXR0[3]/RMII_CRS_DV/AXR2[2]/GP3[3] Control
0 Pin is 3-stated.
1h Selects Function AXR0[3]
2h Selects Function RMII_CRS_DV
3h Reserved
4h Selects Function AXR2[2]
5h-7h Reserved
8h Selects Function GP3[3]
9h-Fh Reserved
15-12 PINMUX10_15_12 D8 113 AXR0[2]/RMII_TXEN/AXR2[3]/GP3[2] Control
0 Pin is 3-stated.
1h Selects Function AXR0[2]
2h Selects Function RMII_TXEN
3h Reserved
4h Selects Function AXR2[3]
5h-7h Reserved
8h Selects Function GP3[2]
9h-Fh Reserved
11-8 PINMUX10_11_8 C8 112 AXR0[1]/RMII_TXD[1]/ACLKX2/GP3[1] Control
0 Pin is 3-stated.
1h Selects Function AXR0[1]
2h Selects Function RMII_TXD[1]
3h Reserved
4h Selects Function ACLKX2
5h-7h Reserved
8h Selects Function GP3[1]
9h-Fh Reserved
7-4 PINMUX10_7_4 B8 111 AXR0[0]/RMII_TXD[0]/AFSR2/GP3[0] Control
0 Pin is 3-stated.
1h Selects Function AXR0[0]
2h Selects Function RMII_TXD[0]
3h Reserved
4h Selects Function AFSR2
5h-7h Reserved
8h Selects Function GP3[0]
9h-Fh Reserved
3-0 PINMUX10_3_0 L4 — AMUTE0/RESETOUT Control
0 Selects Function RESETOUT
1h Selects Function AMUTE0
2h-7h Reserved
8h Selects Function RESETOUT
9h-Fh Reserved
