System Configuration (SYSCFG) Module
Table 10-39. Pin Multiplexing Control 17 Register (PINMUX17) Field Descriptions (continued)
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
15-12 PINMUX17_15_12 P8 26 EMA_BA[1]/LCD_D[5]/UHPI_HHWIL/GP1[13] Control
0 Pin is 3-stated.
1h Selects Function EMA_BA[1]
2h Selects Function LCD_D[5]
3h Reserved
4h Selects Function UHPI_HHWIL
5h-7h Reserved
8h Selects Function GP1[13]
9h-Fh Reserved
11-8 PINMUX17_11_8 N11 42 EMA_A[12]/LCD_MCLK/GP1[12] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[12]
2h Selects Function LCD_MCLK
3h-7h Reserved
8h Selects Function GP1[12]
9h-Fh Reserved
7-4 PINMUX17_7_4 P11 41 EMA_A[11]/LCD_AC_ENB_CS/GP1[11] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[11]
2h Selects Function LCD_AC_ENB_CS
3h-7h Reserved
8h Selects Function GP1[11]
9h-Fh Reserved
3-0 PINMUX17_3_0 N8 27 EMA_A[10]/LCD_VSYNC/GP1[10] Control
0 Pin is 3-stated.
1h Selects Function EMA_A[10]
2h Selects Function LCD_VSYNC
3h-7h Reserved
8h Selects Function GP1[10]
9h-Fh Reserved
