FlexRay Module Registers
1327
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
Table 26-88. Communication Controller Registers (continued)
Offset Acronym Register Description Section
120h SFS Sync Frame Status Register Section 26.3.2.4.7
124h SWNIT Symbol Window and NIT Status Register Section 26.3.2.4.8
128h ACS Aggregated Channel Status Register Section 26.3.2.4.9
130h-168h ESIDn Even Sync ID Register [1 to 15] Section 26.3.2.4.10
170h-1A8h OSIDn Odd Sync ID Register [1 to 15] Section 26.3.2.4.11
1B0h-1B8h NMVn Network Management Vector Register [1 to 3] Section 26.3.2.4.12
Message Buffer Control Registers
300h MRC Message RAM Configuration Register Section 26.3.2.5.1
304h FRF FIFO Rejection Filter Register Section 26.3.2.5.2
308h FRFM FIFO Rejection Filter Mask Register Section 26.3.2.5.3
30Ch FCL FIFO Critical Level Register Section 26.3.2.5.4
Message Buffer Status Registers
310h MHDS Message Handler Status Section 26.3.2.6.1
314h LDTS Last Dynamic Transmit Slot Section 26.3.2.6.2
318h FSR FIFO Status Register Section 26.3.2.6.3
31Ch MHDF Message Handler Constraints Flags Section 26.3.2.6.4
320h TXRQ1 Transmission Request Register 1 Section 26.3.2.6.5
324h TXRQ2 Transmission Request Register 2 Section 26.3.2.6.5
328h TXRQ3 Transmission Request Register 3 Section 26.3.2.6.5
32Ch TXRQ4 Transmission Request Register 4 Section 26.3.2.6.5
330h NDAT1 New Data Register 1 Section 26.3.2.6.6
334h NDAT2 New Data Register 2 Section 26.3.2.6.6
338h NDAT3 New Data Register 3 Section 26.3.2.6.6
33Ch NDAT4 New Data Register 4 Section 26.3.2.6.6
340h MBSC1 Message Buffer Status Changed Register 1 Section 26.3.2.6.7
344h MBSC2 Message Buffer Status Changed Register 2 Section 26.3.2.6.7
348h MBSC3 Message Buffer Status Changed Register 3 Section 26.3.2.6.7
34Ch MBSC4 Message Buffer Status Changed Register 4 Section 26.3.2.6.7
Identification Registers
3F0h CREL Core Release Register Section 26.3.2.7.1
3F4h ENDN Endian Register Section 26.3.2.7.2
Input Buffer
400h-4FCh WRDSn Write Data Section Register [1 to 64] Section 26.3.2.8.1
500h WRHS1 Write Header Section Register 1 Section 26.3.2.8.2
504h WRHS2 Write Header Section Register 2 Section 26.3.2.8.3
508h WRHS3 Write Header Section Register 3 Section 26.3.2.8.4
510h IBCM Input Buffer Command Mask Register Section 26.3.2.8.5
514h IBCR Input Buffer Command Request Register Section 26.3.2.8.6
Output Buffer
600h-6FCh RDDSn Read Data Section Register [1 to 64] Section 26.3.2.9.1
700h RDHS1 Read Header Section Register 1 Section 26.3.2.9.2
704h RDHS2 Read Header Section Register 2 Section 26.3.2.9.3
708h RDHS3 Read Header Section Register 3 Section 26.3.2.9.4
70Ch MBS Message Buffer Status Register Section 26.3.2.9.5
710h OBCM Output Buffer Command Mask Register Section 26.3.2.9.6
714h OBCR Output Buffer Command Request Register Section 26.3.2.9.7
