FlexRay Module Registers
www.ti.com
1326
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
FlexRay Module
Table 26-88. Communication Controller Registers
Offset Acronym Register Description Section
Special Registers
00h ECC_CTRL ECC Control Register Section 26.3.2.1.1
04h ECCDSTAT ECC Diagnostic Status Register Section 26.3.2.1.2
08h ECCTEST ECC Test Register Section 26.3.2.1.3
0Ch SBESTAT Single-Bit Error Status Register Section 26.3.2.1.4
10h TEST1 Test Register 1 Section 26.3.2.1.5
14h TEST2 Test Register 2 Section 26.3.2.1.6
1Ch LCK Lock Register Section 26.3.2.1.7
Interrupt Registers
20h EIR Error Interrupt Register Section 26.3.2.2.1
24h SIR Status Interrupt Register Section 26.3.2.2.2
28h EILS Error Interrupt Line Select Register Section 26.3.2.2.3
2Ch SILS Status Interrupt Line Select Register Section 26.3.2.2.4
30h EIES Error Interrupt Enable Set Register Section 26.3.2.2.5
34h EIER Error Interrupt Enable Reset Register Section 26.3.2.2.5
38h SIES Status Interrupt Enable Set Register Section 26.3.2.2.6
3Ch SIER Status Interrupt Enable Reset Register Section 26.3.2.2.6
40h ILE Interrupt Line Enable Register Section 26.3.2.2.7
44h T0C Timer 0 Configuration Register Section 26.3.2.2.8
48h T1C Timer 1 Configuration Register Section 26.3.2.2.9
4Ch STPW1 Stop Watch Register 1 Section 26.3.2.2.10
50h STPW2 Stop Watch Register 2 Section 26.3.2.2.11
Communication Controller Control Registers
80h SUCC1 SUC Configuration Register 1 Section 26.3.2.3.1
84h SUCC2 SUC Configuration Register 2 Section 26.3.2.3.2
88h SUCC3 SUC Configuration Register 3 Section 26.3.2.3.3
8Ch NEMC NEM Configuration Register Section 26.3.2.3.4
90h PRTC1 PRT Configuration Register 1 Section 26.3.2.3.5
94h PRTC2 PRT Configuration Register 2 Section 26.3.2.3.6
98h MHDC MHD Configuration Register 1 Section 26.3.2.3.7
A0h GTUC1 GTU Configuration Register 1 Section 26.3.2.3.8
A4h GTUC2 GTU Configuration Register 2 Section 26.3.2.3.9
A8h GTUC3 GTU Configuration Register 3 Section 26.3.2.3.10
ACh GTUC4 GTU Configuration Register 4 Section 26.3.2.3.11
B0h GTUC5 GTU Configuration Register 5 Section 26.3.2.3.12
B4h GTUC6 GTU Configuration Register 6 Section 26.3.2.3.13
B8h GTUC7 GTU Configuration Register 7 Section 26.3.2.3.14
BCh GTUC8 GTU Configuration Register 8 Section 26.3.2.3.15
C0h GTUC9 GTU Configuration Register 9 Section 26.3.2.3.16
C4h GTUC10 GTU Configuration Register 10 Section 26.3.2.3.17
C8h GTUC11 GTU Configuration Register 11 Section 26.3.2.3.18
Communication Controller Status Registers
100h CCSV Communication Controller Status Vector Register Section 26.3.2.4.1
104h CCEV Communication Controller Error Vector Register Section 26.3.2.4.2
110h SCV Slot Counter Value Register Section 26.3.2.4.3
114h MTCCV Macrotick and Cycle Counter Value Register Section 26.3.2.4.4
118h RCV Rate Correction Value Register Section 26.3.2.4.5
11Ch OCV Offset Correction Value Register Section 26.3.2.4.6
