Command Manual – Port
Quidway S8500 Series Routing Switches Chapter 4 RPR Port Configuration Commands
Huawei Technologies Proprietary
4-10
Example
# Display protection information.
<Quidway> dis rpr protection
Protection information of the interface: RprPos6/1/1
Protection mode configured: steer
Protection mode effective: steer
Protection reversion mode: revertive
MAC address of the east neighbour:0000-0000-0000
MAC address of the west neighbour:0000-0000-0000
Protection State of the east span:sf
Protection State of the west span:sf
Edge status of the east span: true
Edge status of the west span: true
The number of protections on the east span:1
The number of protections on the west span:1
Last protection time on the east span:
Last protection time on the west span:
Protection start time on the east span:2001.03.25 04:51:13
Protection start time on the west span:2001.03.25 04:51:13
Table 4-4 Description on the fields of the display rpr protection command
Field Description
Protection information of the interface Protection information of the port
Protection mode configured Configured protection mode
Protection mode effective Currently effective protection mode
Protection reversion mode Recovery protection mode
MAC address of the east neighbor MAC address of the east neighbor node
MAC address of the west neighbor MAC address of the west neighbor node
Protection State of the east span Protection status of the east span
Protection State of the west span Protection status of the west span
Edge status of the east span Edge status of the east span
Edge status of the west span Edge status of the west span
The number of protections on the east
span
The number of protections on the east
span
The number of protections on the west
span
The number of protections on the west
span
Last protection time on the east span Last protection time on the east span
Last protection time on the west span Last protection time on the west span
