Huawei Quidway S8500 Series User Manual

Command Manual – Port
Quidway S8500 Series Routing Switches Chapter 4 RPR Port Configuration Commands
Huawei Technologies Proprietary
4-13
Description
Use the display rpr timers command to display all configurable RPR timer values.
Example
#Query all RPR timer values.
<Quidway> display rpr timers RPR2/1/1
All the timers' value of interface RprPos4/1/1
TP fast timer: 10ms
TP slow timer: 100ms
TC fast timer: 10ms
TC slow timer: 100ms
ATD timer: 1s
WTR timer: 20s
Holdoff timer: 0ms
Keepalive timer: 3ms
Topology stability timer: 40ms
FDD timer: 100ms
Table 4-5 Description on the fields of the display rpr timers command
Field Description
All the timers' value of interface All the timers' values of the port
TP fast timer TP fast timer
TP slow timer TP slow timer
TC fast timer TC fast timer
TC slow timer TC slow timer
ATD timer ATD timer
WTR timer WTR timer
Holdoff timer Holdoff timer
Topology stability timer Stable topology timer
FDD timer FDD timer
4.1.10 display rpr topology
Syntax
display rpr topology { all | ring | local | stations } [ verbose ] [ rprpos
[ interface-number ]
