Table 10-23. Pin Multiplexing Control 1 Register (PINMUX1) Field Descriptions (continued)
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
11-8 PINMUX1_11_8 D10 103 EMB_A[0]/GP7[2] Control
0 Pin is 3-stated.
1h Selects Function EMB_A[0]
2h-7h Reserved
8h Selects Function GP7[2]
9h-Fh Reserved
7-4 PINMUX1_7_4 C9 107 EMB_BA[0]/GP7[1] Control
0 Pin is 3-stated.
1h Selects Function EMB_BA[0]
2h-7h Reserved
8h Selects Function GP7[1]
9h-Fh Reserved
3-0 PINMUX1_3_0 B9 106 EMB_BA[1]/GP7[0] Control
0 Pin is 3-stated.
1h Selects Function EMB_BA[1]
2h-7h Reserved
8h Selects Function GP7[0]
9h-Fh Reserved
